LATER TORNADO/SUPER TORNADO

AND LG15V

R54 Trigger strut (pair) £4.00

R55 Sear unit £7.00

R56 Trigger blade £6.50

R57 Trigger spring £1.50

R59 Front stock screw locking washer (pair) £2.00

R29  Front trigger guard bolt £3.80

R62 Trigger adjusting screw £2.50

R76 RELUM PISTON

For late Tornado, Super Tornado. model 527 fits any Relum rifle with trigger that is adjustable through the trigger guard. £12.00 Can be sent to an RFD only, you need to contact us before ordering.

OPEN SIGHTS, later models

R5 Rearsight elevation pin and circlip £1.50

R1 Rearsight blade/body £5.00

R2 Elevation adjusting screw £4.00

R3 Windage adjusting screw £5.00

R4 windage adjusting retaining screw £1.50

R6 Rearsight elevation spring £1.50

R7 Rearsight windage spring £1.50

R8 Complete rearsight assembly £16.00

R10 Front sight retaining screw £1.50

R11 Front sight hood £12.00

PARTS FOR ALL MODELS:

R17 Trigger guard (early type) £9.00

R18 Trigger guard (later type) perfect condition £8.00

R18SS Trigger guard (later type) shop soiled units, these have slight speckling of surface but are perfectly functional but cosmetically flawed/sub standard finish. 5.00

R19 Trigger unit pin £1.00

OPEN SIGHTS, Early models

These sights can also fit (or be made to fit) Webley Junior, Jaguar and Ranger, Milbro Diana rifles, Haenels etc and many small tin plate rifles with dove tails to accept them. Very useful when original parts can not be obtained or are very expensive.

R30 -  Rear leaf sight and adjusting screw £9.00

Bulk deals available 10 rear sights for £40.00

MODEL 527/427/522 (TAURUS/ZEPHYR)

R20 Breech seal (synthetic) £3.00

R21 STOCK - In perfect as new condition. £28.00

R75c Cocking lever £8.00

R24 Barrel detent latch £4.00

R25 Barrel axis bolt £6.00

R52 Mainspring £15.00

R29 Front trigger guard bolt £3.80OU

R72 Cylinder end cap knurled £7.50

Late model Tornado/Super Tornado We can supply every part for this gun

R80 Rearsight retaining pin £1.00

R81  Under lever detent spring £1.50

R82 Under lever detent retaining pin £1.00

R41 Under lever retaining detent ball £4.50

R83 Butt pad screw £1.00

R75A Length 180mm thickness at hole end 5.5mm. For older break barrel rifles. £9.50

R75B for LG15 late Tornado £8.00

R75C for 522/427 break barrel £8.00

Cocking links

R75D length is 72mm overall £3.50

R26 Leather breech seal  822 £4 00

UNDERLEVER - TORNADO, ZODIAC and 322, (LG11)

R33 Loading tap .22 cal £12.00

R34 Loading tap retaining nut £4.00

R35 Loading tap tensioning spring £2.00

R36 Tap, spring and nut assembly (.22)  £17.00

R37 Underlever axis bolt £4.50

R38 Underlever axis bolt lock screw £2.50

R39 Loading tap stop screw £2.50

R40 Cocking link axis screw £3.00

R41 Underlever retaining detent ball £4.50

R74 Rear trigger guard screw £2.50

R73 Cylinder end plug £7.50

R45 End plug retaining pin 6mm thick £2.00

R46 Cocking lever short link £2.00

R47 Front stock bolt £6.10 OUT OF STOCK

R49 Underlever with ball latch NO LONGER AVAILABLE

R48 Relum cocking link rejuvenation set - leaf spring, fixing rivet and synthetic bushing £3.00

R32 Cocking linkLeaf spring only £2.00

R79 Loading tap .177 cal (rare item, limited stock)  £16.00 SOLD OUT

T

R88 - Loading tap washer £1.50 SOLD OUT

CLICK HERE

All parts available for RELUM 527 & 522 (Taurus/Zephyr

RELUM POWER.....

This is the late style rear sight unit R8. If your rifle is fitted with one of these it will have the later style trigger assembly.

This is fore sight unit for later  Relum rifles. It fits on to two grooves which run along the barrel, we no longer have this assembly.

R90F - Front sight post for early Relum break barrels and under levers. £15.00

May require very slight filing for perfect fit

PROTEK SUPPLIES are the main source for Relum parts.

R50 - Mainspring set comprising Relum outer and inner springs. Made in UK to higher specification than original £18.00

R51 - Inner spring only £8.50

R51 - Inner spring only £8.50

POWER PLANT KIT

For .22 Relum Tornado

Restore the performance of your Tornado easily with this full kit of parts. You get the twin spring set, piston washer, rivet & spacer, loading tap and lithium grease.

Order part no R100 £32.00

This gives you a saving of £7 over buying the parts separately

~~~ Most parts in stock for dispatch usually same day ~~~

~~~ Flat rate postage charge of £3.90 (air guns  £12.00 to send) ~~~

Air guns can not be ordered by Paypal. Phone us to place order using credit/debit card. Barrels, pistons and air guns later than 1939 can only be sent to a registered fire arms dealer. Postage rates shown for UK if outside of UK contact us first. 01243 824284

Place your order

CLICK HERE

R61 Sear £6.50

R44 Trigger £8.00

R103 - pin for early trigger unit. £1.20 for 2

R50 - Mainspring set comprising Relum outer and inner springs. Made in UK to higher specification than original £18.00

Phone up & order it

01243 824284

Quick & easy

R105 - Front trigger guard bolt and trigger adjusting screw, complete assembly Fits early Tornado, Telly 200, Zodiac, 822, LP29, Sport, Repetier These are manufactured to the highest standard and have the original spec thread. £28.53

R58 Front stock screws, fits late model, sold as a pair  £3.25 for the pair

R58 Front stock screw £3.25 for a pair

R107 - Underlever retaining block, used good condition with pins £14.00

We have air gun stocks…click here

TELLY 200, 822 and LP25

R109 - Detent retaining catch  £3.00

R110 - Grub screw for detent retaining catch GRUB SCREW ONLY £1.50

R109

R110

This is a piston from an early Tornado. We may have one in stock, you need to contact us on 01243 824284 for availability. Can be sent to RFD or you can pick up from our shop.

R31 Rear leaf sight adjusting screw only  £1.00

PISTON WASHER RIVET & SPACER

R15 Rivet £3.00

R96 Leather piston washer £6.00

R115 Spacer £4.00

Buy all 3 parts and save £3.00 piston washer, rivet and spacer £10.00 ORDER AS R16

Front view

Side view

EXCLUSIVE..MAKE YOUR RELUM SMOOTHER AND MORE CONSISTENT

High quality German made piston seal, specially machined solid spacer and rivet. Smoother and more consistent shooting .


Here is one fitted

Order part no R118 £24.00

NEW!!!

Piston not included in kit!

R102 - Trigger/sear spring for early type trigger mechanism £5.00

R124 - Pin for holding cylinder end plug 4.4mm thick £2.00

R47 - Front stock screw fits early model, head size 6.9mm and fit in to a metal cup let in to the stock. £6.10 each OUT OF STOCK

R125  Cup washer for front stock bolt. (Part R47 fits through this) £4.00

R125  Cup washer for front stock bolt. (Part R47 fits through this) £4.00

Order part No R130 £24.00

REPLACEMENT SPRING KIT FOR ALL RELUM RIFLES

Single spring for smooth operation and easier cocking, with much better long term performance. This single spring kit will still give the same power as the two spring set originally used yet will cock easier and shoot smoother.

SUPER SMOOTH EASY TO COCK EXCELLENT POWER

Comprises high quality mainspring (B34), spring guide, end cap spacer and some spring grease.

THIS KIT ALSO AVAILABLE WITH THE SINGLE SMOOTHER SPRING OPTION INSTEAD OF THE TWO SPRING OPTION

ORDER PART NUMBER R131 £40.00

M473 - Front sight unit modified to fit Original/Diana, Relum, Weihrauch and Anschutz.  £18.00

Three angles shown, one supplied

2 angles shown one supplied

Image shows underside and top angle of the same sight hood

R106 - Just the centre screw, by itself. Trigger adjusting screw. £7.00

THIS WILL NOT FIT EARLIER MODELS WITH THIS TYPE OF SIGHT

R99 - Scope rail for model 322/early Tornado. Made specially for us to a high standard, simply screw in place using the 3 counter sunk finished screws supplied using the allen key which is also supplied. £25.00

SCOPE RAIL
